Thermal Induced Interface Mechanical Response Analysis of SMT Lead-Free Solder Joint and Its Adaptive Optimization
Liu, Shaoyi Yan, Yuefei Zhou, Yijiang Han, Baoqing Wang, Benben Zhang, Daxing Xue, Song Wang, Zhihai Yu, Kunpeng Shi, Yu
Liu, Shaoyi
Yan, Yuefei
Zhou, Yijiang
Han, Baoqing
Wang, Benben
Zhang, Daxing
Xue, Song
Wang, Zhihai
Yu, Kunpeng
Shi, Yu
Advisors
Editors
Other Contributors
EPub Date
Publication Date
2022-06-08
Submitted Date
Collections
Files
Loading...
Article
Adobe PDF, 4.52 MB
Other Titles
Abstract
Surface mount technology (SMT) plays an important role in integrated circuits, but due to thermal stress alternation caused by temperature cycling, it tends to have thermo-mechanical reliability problems. At the same time, considering the environmental and health problems of lead (Pb)-based solders, the electronics industry has turned to lead-free solders, such as ternary alloy
Sn-3Ag-0.5Cu (SAC305). As lead-free solders exhibit visco-plastic mechanical properties significantly affected by temperature, their thermo-mechanical reliability has received considerable attention. In this study, the interface delamination of an SMT solder joint using a SAC305 alloy under temperature cycling has been analyzed by the nonlinear finite element method. The results indicate that the highest contact pressure at the four corners of the termination/solder horizontal interface means that delamination is most likely to occur, followed by the y-direction side region of the solder/land interface and the top arc region of the termination/solder vertical interface. It should be noted that in order to keep the shape of the solder joint in the finite element model consistent with the actual situation after the reflow process, a minimum energy-based morphology evolution method has been incorporated into the established finite element model. Eventually, an Improved Efficient Global Optimization (IEGO) method was used to optimize the geometry of the SMT solder joint in order to reduce the contact pressure at critical points and critical regions. The optimization result shows that the contact pressure at the critical points and at the critical regions decreases significantly, which also means that the probability of thermal-induced delamination decreases.
Citation
Liu, S., Yan, Y., Zhou, Y., Han, B., Wang, B., Zhang, D., Xue, S., Wang, Z., Yu, K., Shi, Y., & Wang, C. (2022). Thermal induced interface mechanical response analysis of SMT lead-free solder joint and its adaptive optimization. Micromachines, 13(6), 908. https://doi.org/10.3390/mi13060908
Publisher
MDPI
Journal
Micromachines
Research Unit
DOI
10.3390/mi13060908
PubMed ID
PubMed Central ID
Type
Article
Language
Description
Series/Report no.
ISSN
No print ISSN
EISSN
2072-666X
